Summary Features：

NKMB F series include 67 series, 68 series, 69 series, 60 series, 62 series with flange

Product Details

Product Introduction

NKMB F series include 67 series, 68 series, 69 series, 60 series, 62 series with flange

NKMB deep groove ball bearing 67 series parameter table (partial examples)

Model	d (mm)	D (mm)	D1 (mm)	D2 (mm)	Max Speed (Grease / Oil)	Cr (N)	Cor (N)
MF85	5	8	8	9	38,000 / 46,000	310	120
MF95	5	9	9	10	36,000 / 44,000	430	168
MF105	5	10	12	12	34,000 / 42,000	430	168
F685	5	11	12.5	12.5	32,000 / 40,000	715	281
F695	5	13	15	15	30,000 / 38,000	1080	430
F605	5	14	16	16	28,000 / 36,000	1330	505
F625	5	16	18	18	26,000 / 34,000	1730	670
F635	5	19	22	22	24,000 / 32,000	2340	885
MF106	6	10	11.2	11.2	22,000 / 30,000	495	218
MF126	6	12	13.6	13.6	20,000 / 28,000	715	292
F686	6	13	15	15	18,000 / 26,000	1080	440
F696	6	15	17	17	16,000 / 24,000	1730	670
F606	6	17	19	19	14,000 / 20,000	2260	835
F626	6	19	22	22	12,000 / 18,000	2340	885
F636	6	22	25	25	10,000 / 16,000	3300	1370
MF117	7	11	12.2	12.2	9,000 / 14,000	455	201
MF137	7	13	14.2	14.6	8,000 / 12,000	540	276
F687	7	14	16	16	7,000 / 10,000	1170	510
F697	7	17	19	19	6,000 / 9,000	1610	715
F607	7	19	22	22	5,000 / 8,000	2340	885
F627	7	22	25	25	4,000 / 7,000	3300	1370
MF128	8	12	13.2	13.6	38,000 / 46,000	545	275
MF148	8	14	15.6	15.6	36,000 / 44,000	820	385
F688	8	16	18	18	34,000 / 42,000	1610	710
F698	8	19	22	22	32,000 / 40,000	2240	910
F608	8	22	25	25	30,000 / 38,000	3300	1370
